Stainless Steel Round Bar 17-4

Stainless Steel Round Bar 17-4 is a round shaped bar of 17-4 Stainless Steel.

Grade 17-4 PH is a chromium-nickel grade of stainless that may be hardened by a single low temperature precipitation-hardening heat treatment.

It has excellent mechanical properties and a high strength level may be obtained by using the hardening treatment.

Scaling and distortion is minimized.

Grade 17-4 PH should not be used in the solution treated condition.

The strength and corrosion resistance properties of 17-4 hold up well and it has service temperatures up to 800° F.

The fabrication techniques for this steel is similar to those established for the regular stainless grades.

17-4 machines well, has excellent welding characteristics and forges easily.

• Machinability: Good
• Forming: Fair
• Weldability: Good
• Forging: Fair
• Hot Working: Good

• Gate valves
• Chemical processing equipment
• Firearms production
• Pump shafts, gears, plungers
• Valve stems, balls, bushings, seats
• Fasteners

• Density: 0.280 lb/in³
• Shear modulus: 11200 ksi
• Elastic modulus: 27557-30458 ksi
• Poisson’s ratio: 0.27-0.30
• Hardness Brinell: 352
